中红外光谱法测定土壤碳的研究进展

王君玮 袁会敏 江荣风 王雁峰 武良 王盛锋

王君玮, 袁会敏, 江荣风, 王雁峰, 武 良, 王盛锋. 中红外光谱法测定土壤碳的研究进展[J]. 土壤通报, 2021, 52(1): 233 − 241 doi: 10.19336/j.cnki.trtb.2020042501
引用本文: 王君玮, 袁会敏, 江荣风, 王雁峰, 武 良, 王盛锋. 中红外光谱法测定土壤碳的研究进展[J]. 土壤通报, 2021, 52(1): 233 − 241 doi: 10.19336/j.cnki.trtb.2020042501
WANG Jun-wei, YUAN Hui-min, JIANG Rong-feng, WANG Yan-feng, WU Liang, WANG Sheng-feng. Research Advance in the Determination of Soil Carbon by Mid-infrared Spectroscopy[J]. Chinese Journal of Soil Science, 2021, 52(1): 233 − 241 doi: 10.19336/j.cnki.trtb.2020042501
Citation: WANG Jun-wei, YUAN Hui-min, JIANG Rong-feng, WANG Yan-feng, WU Liang, WANG Sheng-feng. Research Advance in the Determination of Soil Carbon by Mid-infrared Spectroscopy[J]. Chinese Journal of Soil Science, 2021, 52(1): 233 − 241 doi: 10.19336/j.cnki.trtb.2020042501

中红外光谱法测定土壤碳的研究进展

doi: 10.19336/j.cnki.trtb.2020042501
基金项目: 国家重点研发计划项目(2016YFD0200403,2016YFE0101100,2017YFD0200201,2016YFD0200401)资助
详细信息
    作者简介:

    王君玮(1996−),女,山东青岛人,硕士研究生,主要从事土壤养分快速测定的研究。E-mail: WJW00223830@163.com

    通讯作者:

    E-mail: hmyuan@cau.edu.cn

  • 中图分类号: S-1

Research Advance in the Determination of Soil Carbon by Mid-infrared Spectroscopy

  • 摘要: 土壤碳不仅是影响土壤肥力和农业可持续发展的重要因子,也对减缓温室效应有重要意义。因此,土壤碳分析是农业、环境等学科领域的重要研究内容。传统化学分析方法存在测定效率低、实时性差、有污染等缺点,无法满足现代绿色农业快速测定土壤碳的需求。近年来,中红外光谱(mid-infrared spectroscopy, MIR)技术以其操作简便、重现性好、测试速度快、样品用量少、绿色环保和适合批量样品测定的特点,逐渐成为获取土壤碳信息的有效方法。本文简要介绍了中红外光谱分析基本原理,重点论述了该技术在预测土壤碳方面的国内外研究进展及影响因素,并对MIR技术在我国土壤碳定量研究方面的应用前景进行了展望。目前,MIR技术已成功应用于土壤总碳、有机碳、无机碳、炭、水溶性有机碳、微生物量碳、生物量碳、颗粒有机碳、矿物结合有机碳、惰性有机碳等土壤碳组分的预测,为土壤碳分析提供了快速无损的测定手段,也为绿色农业和精准农业的发展提供了先进的技术支撑。
  • 表  1  近十年以来MIR技术在土壤总碳、有机碳及无机碳定量分析中的应用情况

    Table  1.   Application of MIR technology in the quantitative analysis of soil total carbon, organic carbon and inorganic carbon in the past ten years

    参考文献
    Ref.
    仪器
    Ins.
    光谱采集
    Spectral Measurements
    样本信息
    Sample
    指标
    Ind.
    模型
    Model
    评价参数
    Performance parameters
    范围 (cm−1)
    Range
    分辨率 (cm−1
    Resolution
    扫描次数
    Scan time
    R2RMSEp
    (%)
    RPD/
    RPIQb
    [13] Tensor 27 4000 ~ 602 4 32 971s./18c.
    V = 30%
    OC 21数据点间隔平滑 + 一阶导数-PLSR 0.77 0.91a 2.04
    [22] Scimitar2000 6000 ~ 400 4 32 305s./5i.USA
    V = 30%
    TC 均值中心化+Savitzky-Golay卷积平滑+ 一阶导数-PLSR 0.94 3.08 3.91
    Savitzky-Golay卷积平滑 + 一阶导数-RF 0.96 2.28 5.28
    [18] Nicolet 6700 4000 ~ 400 4 32 2086s./FRA
    V = 80%
    OC 5数据点间隔平滑-PLSR 0.89 3.00
    IC 0.97 5.60
    [19] Nicolet 6700 8000 ~ 400 8 60 18005s./AUS
    V = 33%
    TC 基线校正 + 均值中心化-PLSR 0.91 0.431 3.38
    19766s./AUS
    V = 33%
    OC 0.92 0.417 3.62
    2454s./AUS
    V = 33%
    IC 0.93 0.344 4.43
    [23] Scimitar 2000 6000 ~ 400 4 32 1014s./Florida
    V = 30%
    TC 吸光度转化-PLSR 0.95 0.24 4.60
    5窗口Savitzky-Golay卷积平滑 + 一阶导数-RF 0.94 0.28 3.90
    OC 吸光度转化-PLSR 0.96 0.23 4.70
    5窗口Savitzky-Golay卷积平滑 + 一阶导数-RF 0.94 0.28 3.90
    [20] Vertex 70 7498 ~ 600 4 32 20102s./NSSC
    V = 50%
    TC 10波段窗口平均-PLSR 0.95 1.90 4.44
    10波段窗口平均-ANN 0.97 1.34 6.32
    17298s./NSSC
    V = 50%
    OC 10波段窗口平均-PLSR 0.95 1.89 4.55
    10波段窗口平均-ANN 0.99 0.75 11.46
    7861s./NSSC
    V = 50%
    IC 10波段窗口平均-PLSR 0.97 0.26 5.61
    10波段窗口平均-ANN 0.99 0.13 11.23
    [24] Vertex 70 7498 ~ 600 4 32 14594s./KSSL
    V=25%
    TC 11窗口Savitzky-Golay卷积平滑 + 标准正态变量变换-PLSR 0.95 0.37 1.83b
    11窗口Savitzky-Golay卷积平滑 + 标准正态变量变换-Cubist 0.97 0.28 2.41 b
    标准正态变量变换-CNN 0.98 0.21 3.12 b
    OC 11窗口Savitzky-Golay卷积平滑 + 标准正态变量变换-PLSR 0.94 0.35 1.37 b
    11窗口Savitzky-Golay卷积平滑 + 标准正态变量变换-Cubist 0.97 0.24 2.02 b
    标准正态变量变换-CNN 0.98 0.20 2.37 b
    [21] Tensor 27 7498 ~ 600 4 32 285s./20c.SSA
    V=30%
    OC 吸光度转化 + Savitzky-Golay卷积一阶导数-PLSR 0.80 0.52 1.94 b
    [25] ExoScan 4100 6000 ~ 650 8 15 458s./CNSA
    V=25%
    TC 去趋势法-BAG 0.98 0.22 6.68
    去趋势法-RF 0.96 0.28 5.25
    去趋势法-DT 0.68 0.84 1.76
    去趋势法-Bagging 0.94 0.38 3.94
    去趋势法- RR 0.97 0.25 5.92
    去趋势法-PLSR 0.94 0.30 4.13
    [26] Agilent 4300 4000 ~ 650 8 64 90s./GER
    V=33%
    OC 吸光度转化 + 多元散射校正-PLSR 0.63 0.17 1.65
      注:s.:样本数;c.:国家;i.:岛屿;V:验证集样本量占总样本量百分比;a:单位转化,由g kg−1转化为%;-:未知;TC:总碳;OC:有机碳;IC:无机碳;b:RPIQ值;NSSC:USDA–NRCS美国土壤调查中心;KSSL:美国Kellogg土壤调查实验室;SSA:撒哈拉沙漠以南的非洲地区;CNSA:澳大利亚CSIRO国家土壤档案馆;PLSR:偏最小二乘回归;RF:随机森林;ANN:人工神经网络;CNN:卷积神经网络;GPR:高斯回归过程;DT:决策树;RR:回归规则。
    下载: 导出CSV
  • [1] 余 健, 房 莉, 卞正富, 等. 土壤碳库构成研究进展[J]. 生态学报, 2014, 34(17): 4829 − 4838.
    [2] Minasny B, Malone B P, Mcbratney A B, et al. Soil carbon 4 per mille[J]. Geoderma, 2017, 292: 59 − 86. doi: 10.1016/j.geoderma.2017.01.002
    [3] 潘根兴, 陆海飞, 李恋卿, 等. 土壤碳固定与生物活性: 面向可持续土壤管理的新前沿[J]. 地球科学进展, 2015, 30(8): 940 − 951. doi: 10.11867/j.issn.1001-8166.2015.08.0940
    [4] 蔡 苗. 农田生态系统土壤碳固持效应研究[J]. 绿色科技, 2017, 18: 1 − 4.
    [5] Bellon-maurel V, Mcbratney A. Near-infrared (NIR) and mid-infrared (MIR) spectroscopic techniques for assessing the amount of carbon stock in soils-Critical review and research perspectives[J]. Soil Biology and Biochemistry, 2011, 43(7): 1398 − 1410. doi: 10.1016/j.soilbio.2011.02.019
    [6] 褚小立. 化学计量学方法与分子光谱分析技术[M]. 北京: 化学工业出版社, 2011.
    [7] Soriano-disla J M, Janik L J, Viscarra Rossel R A, et al. The performance of Visible, Near-, and Mid-Infrared reflectance spectroscopy for prediction of soil physical, chemical, and biological properties[J]. Applied Spectroscopy Reviews, 2014, 49(2): 139 − 186. doi: 10.1080/05704928.2013.811081
    [8] 曲 楠, 朱明超, 窦 森. 近红外与中红外光谱技术在土壤分析中的应用[J]. 分析测试学报, 2015, 34(1): 120 − 126. doi: 10.3969/j.issn.1004-4957.2015.01.020
    [9] 张 进, 何 鑫, 万瑞英. 漫反射傅里叶变换红外光谱技术在定量分析中的应用[J]. 理化检验(化学分册), 2015, 51(9): 1347 − 1352.
    [10] 杜昌文. 土壤红外光声光谱原理及应用[M]. 北京: 科学出版社, 2012.
    [11] Bellon-maurel V, Fernandez-ahumada E, Palagos B, et al. Critical review of chemometric indicators commonly used for assessing the quality of the prediction of soil attributes by NIR spectroscopy[J]. TrAC Trends in Analytical Chemistry, 2010, 29(9): 1073 − 1081. doi: 10.1016/j.trac.2010.05.006
    [12] Chang C W, Laird D A, Mausbach M J, et al. Near-infrared reflectance spectroscopy–principal components regression analyses of soil properties[J]. Soil Science Society of America Journal, 2001, 65(2): 480 − 490. doi: 10.2136/sssaj2001.652480x
    [13] Terhoeven-Urselmans T, Vagen T, Spaargaren O, et al. Prediction of Soil Fertility Properties from a Globally Distributed Soil Mid-Infrared Spectral Library[J]. Soil Science Society of America Journal, 2010, 74(5): 1792 − 1799. doi: 10.2136/sssaj2009.0218
    [14] 李桂花, 叶小兰, 杨 森, 等. 催化氧化法与直接燃烧法测定土壤总碳之比较[J]. 中国土壤与肥料, 2014, (4): 97 − 101. doi: 10.11838/sfsc.20140419
    [15] Reeves J B. Near- versus mid-infrared diffuse reflectance spectro scopy for soil analysis emphasizing carbon and laboratory versus on-site analysis: Where are we and what needs to be done?[J]. Geoderma, 2010, 158(1): 3 − 14.
    [16] Nocita M, Stevens A, Van Wesemael B, et al. Soil spectroscopy: An alternative to wet chemistry for soil monitoring[J]. Advances in agronomy. Academic Press, 2015, 132: 139 − 159.
    [17] Janik L J, Skjemstad J O. Characterization and analysis of soils using mid-infrared partial least-squares. Ⅱ Correlations with some laboratory data[J]. Soil Research, 1995, 33(4): 637 − 650. doi: 10.1071/SR9950637
    [18] Grinand C, Barthès B G, Brunet D, et al. Prediction of soil organic and inorganic carbon contents at a national scale (France) using mid-infrared reflectance spectroscopy (MIRS)[J]. European Journal of Soil Science, 2012, 63(2): 141 − 151. doi: 10.1111/j.1365-2389.2012.01429.x
    [19] Baldock J A, Hawke B, Sanderman J, et al. Predicting contents of carbon and its component fractions in Australian soils from diffuse reflectance mid-infrared spectra[J]. Soil Research, 2013, 51(8): 577 − 595. doi: 10.1071/SR13077
    [20] Wijewardane N K, Ge Y F, Wills S, et al. Predicting physical and chemical properties of US Soils with a mid-infrared reflectance spectral library[J]. Soil Science Society of America Journal, 2018, 82(3): 722 − 731. doi: 10.2136/sssaj2017.10.0361
    [21] Johnson J, Vandamme E, Senthilkumar K, et al. Near-infrared, mid-infrared or combined diffuse reflectance spectroscopy for assessing soil fertility in rice fields in sub-Saharan Africa[J]. Geoderma, 2019, 35: 113840.
    [22] Mcdowell M L, Bruland G L, Deenik J L, et al. Soil total carbon analysis in Hawaiian soils with visible, near-infrared and mid-infrared diffuse reflectance spectroscopy[J]. Geoderma, 2012, 189 - 190: 312 − 320. doi: 10.1016/j.geoderma.2012.06.009
    [23] Knox N M, Grunwald S, Mcdowell M L, et al. Modelling soil carbon fractions with visible near-infrared (VNIR) and mid-infrared (MIR) spectroscopy[J]. Geoderma, 2015, 239 - 240: 229 − 239. doi: 10.1016/j.geoderma.2014.10.019
    [24] Ng W, Minasny B, Montazerolghaem M, et al. Convolutional neural network for simultaneous prediction of several soil properties using visible/near-infrared, mid-infrared, and their combined spectra[J]. Geoderma, 2019, 352: 251 − 267. doi: 10.1016/j.geoderma.2019.06.016
    [25] Martínez-España R, Bueno-Crespo A, Soto J, et al. Developing an intelligent system for the prediction of soil properties with a portable mid-infrared instrument[J]. Biosystems Engineering, 2019, 177: 101 − 108. doi: 10.1016/j.biosystemseng.2018.09.013
    [26] Hutengs C, Seidel M, Oertel F, et al. In situ and laboratory soil spectroscopy with portable visible-to-near-infrared and mid-infrared instruments for the assessment of organic carbon in soils[J]. Geoderma, 2019, 355: 113900. doi: 10.1016/j.geoderma.2019.113900
    [27] 第五鹏瑶, 卞希慧, 王姿方, 等. 光谱预处理方法选择研究[J]. 光谱学与光谱分析, 2019, 39(9): 2800 − 2806.
    [28] 张津源, 朱海涛. 光谱预处理方法综述[J]. 西部皮革, 2017, 39(16): 14. doi: 10.3969/j.issn.1671-1602.2017.16.011
    [29] Madhavan D B, Kitching M, Mendham D S, et al. Mid-infrared spectroscopy for rapid assessment of soil properties after land use change from pastures to Eucalyptus globulus plantations[J]. Journal of Environmental Management, 2016, 175: 67 − 75.
    [30] Vohland M, Ludwig M, Thiele-Bruhn S, et al. Determination of soil properties with visible to near- and mid-infrared spectroscopy: Effects of spectral variable selection[J]. Geoderma, 2014, 223- 225: 88 − 96. doi: 10.1016/j.geoderma.2014.01.013
    [31] Zou X B, Zhao J W, Povey M J W, et al. Variables selection methods in near-infrared spectroscopy[J]. Analytica Chimica Acta, 2010, 667(1): 14 − 32.
    [32] Deiss L, Margenot A J, Culman S W, et al. Tuning support vector machines regression models improves prediction accuracy of soil properties in MIR spectroscopy[J]. Geoderma, 2020, 365: 114227. doi: 10.1016/j.geoderma.2020.114227
    [33] Hutengs C, Ludwig B, Jung A, et al. Comparison of portable and bench-top spectrometers for mid-infrared diffuse reflectance measurements of Soils[J]. Sensors, 2018, 18(4): 993. doi: 10.3390/s18040993
    [34] Riedel F, Denk M, Müller I, et al. Prediction of soil parameters using the spectral range between 350 and 15, 000 nm: A case study based on the permanent soil monitoring program in Saxony, Germany[J]. Geoderma, 2018, 315: 188 − 198. doi: 10.1016/j.geoderma.2017.11.027
    [35] Soriano-Disla J M, Janik L J, Forrester S T, et al. The use of mid-infrared diffuse reflectance spectroscopy for acid sulfate soil analysis[J]. Sci Total Environ, 2019, 646: 1489 − 1502. doi: 10.1016/j.scitotenv.2018.07.383
    [36] 郭 振, 王小利, 段建军. 土壤活性有机碳的监测及在土地管理中的应用[J]. 山地农业生物学报, 2017, 36(4): 55 − 63.
    [37] 赵 荟. 土壤碳组分及其环境意义概述[J]. 林业建设, 2017, 194(2): 43 − 47.
    [38] 张 国, 曹志平, 胡婵娟. 土壤有机碳分组方法及其在农田生态系统研究中的应用[J]. 应用生态学报, 2011, 22(7): 1921 − 1930.
    [39] Reeves Ⅲ J B, Follett R F, Mccarty G W, et al. Can near or mid-infrared diffuse reflectance spectroscopy be used to determine soil carbon pools?[J]. Communications in Soil Science and Plant Analysis, 2006, 37: 2307 − 2325. doi: 10.1080/00103620600819461
    [40] Yang X M, Xie H T, Drury C F, et al. Determination of organic carbon and nitrogen in particulate organic matter and particle size fractions of Brookston clay loam soil using infrared spectroscopy[J]. European Journal of Soil Science, 2012, 63(2): 177 − 188. doi: 10.1111/j.1365-2389.2011.01421.x
    [41] Zimmermann M, Leifeld J, Fuhrer J. Quantifying soil organic carbon fractions by infrared-spectroscopy[J]. Soil Biology and Biochemistry, 2007, 39(1): 224 − 231. doi: 10.1016/j.soilbio.2006.07.010
    [42] Janik L J, Skjemstad J O, Shepherd K D, et al. The prediction of soil carbon fractions using mid-infrared-partial least square analysis[J]. Soil Research, 2007, 45(2): 73. doi: 10.1071/SR06083
    [43] Ludwig B, Linsler D, Hoper H, et al. Pitfalls in the use of middle-infrared spectroscopy: Representativeness and ranking criteria for the estimation of soil properties[J]. Geoderma, 2016, 268: 165 − 175. doi: 10.1016/j.geoderma.2016.01.010
    [44] Mirzaeitalarposhti R, Demyan M S, Rasche F, et al. MidDRIFTS-PLSR-based quantification of physico-chemical soil properties across two agroecological zones in Southwest Germany: generic independent validation surpasses region specific cross-validation[J]. Nutrient Cycling in Agroecosystems, 2015, 102(2): 265 − 283. doi: 10.1007/s10705-015-9698-1
    [45] Guillou F L, Wetterlind W, Viscarra Rossel R A, et al. How does grinding affect the mid-infrared spectra of soil and their multivariate calibrations to texture and organic carbon?[J]. Soil Research, 2015, 53(8): 913. doi: 10.1071/SR15019
    [46] Stumpe B, Weihermüller L, Marschner B. Sample preparation and selection for qualitative and quantitative analyses of soil organic carbon with mid-infrared reflectance spectroscopy[J]. European Journal of Soil Science, 2011, 62(6): 849 − 862. doi: 10.1111/j.1365-2389.2011.01401.x
    [47] Laub M, Blagodatsky S, Nkwain Y F, et al. Soil sample drying temperature affects specific organic mid-DRIFTS peaks and quality indices[J]. Geoderma, 2019, 355: 113897. doi: 10.1016/j.geoderma.2019.113897
    [48] Ge Y F, Thomasson J A, Morgan C L S. Mid-infrared attenuated total reflectance spectroscopy for soil carbon and particle size determination[J]. Geoderma, 2014, 213: 57 − 63. doi: 10.1016/j.geoderma.2013.07.017
    [49] Peltre C, Bruun S, Du C, et al. Assessing soil constituents and labile soil organic carbon by mid-infrared photoacoustic spectroscopy[J]. Soil Biology and Biochemistry, 2014, 77: 41 − 50. doi: 10.1016/j.soilbio.2014.06.022
    [50] Du C W, Ma Z Y, Zhou J M, et al. Application of mid-infrared photoacoustic spectroscopy in monitoring carbonate content in soils[J]. Sensors and Actuators B: Chemical, 2013, 188: 1167 − 1175. doi: 10.1016/j.snb.2013.08.023
    [51] 彭 义, 解宏图, 李 军, 等. 免耕条件下不同秸秆覆盖量的土壤有机碳红外光谱特征[J]. 中国农业科学, 2013, 46(11): 2257 − 2264. doi: 10.3864/j.issn.0578-1752.2013.11.009
    [52] 郝翔翔, 韩晓增, 邹文秀. 示差红外光谱在土壤有机质组成研究中的应用[J]. 分析化学, 2018, 46(4): 616 − 622. doi: 10.11895/j.issn.0253-3820.171100
    [53] 陈 晨, 李志伟, 董大明. 土壤养分的红外衰减全反射与漫反射光谱同步测量方法[J]. 光谱学与光谱分析, 2017, 37(11): 3557 − 3561.
    [54] Jia X L, Chen S C, Yang Y Y, et al. Organic carbon prediction in soil cores using VNIR and MIR techniques in an alpine landscape[J]. Scientific Reports, 2017, 7(1): 2144. doi: 10.1038/s41598-017-02061-z
    [55] 阎 凯, 许建初, 马怀霞, 等. 快速测定土壤碳氮及其稳定同位素的中红外光谱检测系统: 中国, CN107748144A[P]. 2018-03-02.
    [56] 马怀霞, 阎 凯, Gbadamassi G. O. Dossa, et al 基于中红外光谱法土壤理化性质与稳定性同位素剖面分布[J]. 水土保持研究, 2019, 26(3): 58 − 65.
    [57] 马赵扬, 杜昌文, 周健民. 土壤碳酸钙中红外光声光谱特征及其应用[J]. 光谱学与光谱分析, 2012, 32(5): 1255 − 1258. doi: 10.3964/j.issn.1000-0593(2012)05-1255-04
    [58] 倪玲珊, 岳 荣, 方怒放. 基于中红外漫反射光谱法预测黄土碳酸钙含量[J]. 水土保持研究, 2020, 27(2): 142 − 148.
